Beichen Code: High Density LC Pulp Cleaner
Features
OEM production in accordance with specifications and drawings from clients
Cast iron, carbon steel, or stainless steel for the main body for long-lasting performance
Minimal upkeep and reduced fiber loss
Simple to connect and install
Optimum use of floor space
Product specification
|
Product Name |
High density LC pulp cleaner |
|
Mill Code |
LC pulp cleaner |
|
Category |
High density pulp cleaner |
|
Paper type |
Paper, board, tissue |
|
Principle |
Vortex and centrifugal |
|
Consistency ranges |
0.1%~5% of the pulp slurry |
|
Application |
Recycled fiber cleaning and stock preparation |
|
Package |
Wood cage for cargo and ship transportation |
|
Material |
Cast iron / carbon steel / stainless steel Alumina ceramic for cones |
|
Sizes |
Total height maybe 4 meter, inside diameter of inlet head can be 14cm, 15cm, 17cm, 20cm according to customer drawings |
|
Debris can be removed |
Sand, grit, glass, staples, metal, and other heavy density materials |
|
Features |
Long-lasting materials, vertical installment for floor saving |
Contact salesman and technician for technical assistance
Divided design
The high density pulp cleaner, BCHDLC, features a divided design. The reject chamber, cone cartridge, vortex-designed input head, and optional top cone adapter are its three to four main sections.
Sizes and system configurations can be produced in compliance with customer design.
Product introduction
What is high density hydrocyclone cleaner for recycled paper pulp
A high density pulp cleaner, the BCHDLC series hydrocyclone is used for cleaning and stock preparation of recycled paper pulp. primarily be placed in the pulp mill's initial stage to handle high consistency slurry that includes heavy debris such as metals, glass, grit, and sand. This cleaner works with a broad range of sizes and system configurations, handling consistencies of up to 5.0%.
Why high density hydrocyclone cleaner
The fiber stream produced from OCC and other types of recycled paper is dense with a wide range of impurities. Heavy, damaging material like glass and metal are too big for the hydrocyclone in PA66. For this reason, the OCC and recycled pulp mill require a high density hydrocyclone with a stainless steel body and ceramic linings.
Massive fiber streams can enter the intake head because of its free vortex design and 20 cm internal diameter. One set of BCHDLC is sufficient when combined with vertical sectional layout.
Main Function
High density pulp cleaners are primarily used to gather and eliminate heavy impurities from the fiber stream produced by OCC and recycled paper. The cleaned pulp is then sent to light consistency hydrocyclones for additional cleaning steps.
How it works
The BCHDLC pulp cleaner is a free vortex type separator that effectively removes heavy impurities such as glass, metal, sand, and metal clips. The primary function is to extract heavy impurities from the fiber stream. The unwanted, heavy particles are gathered by centrifugal force and sent to the bottom reject chamber. Accepts that weigh little are streamed to the head and advance to the following phases.
Insights of the design
The BCHDLC high density pulp cleaner features a split design. The reject chamber, cone cartridge, vortex-designed input head, and optional top cone adapter are its three to four main sections.
Sizes and system configurations can be produced in compliance with customer design.
Materials
The primary cleaner body and reject chamber could be made of carbon steel, stainless steel, or cast iron.
Thick Alumina ceramic cones with high wear are used to line the reject chamber and cone cartridge portion.
Details regarding sale
We can provide the complete BCHDLC high density pulp cleaner set in a wooden box.
Separate supplies are available for replacement parts such as the reject chamber, cone cartridge, and inlet head.
Related Service
We can offer size measure, material checking, overall planning, ceramic linings attaching and replacement
Our sales engineer can help on the adjustment and installment on the high density pulp cleaners.
Why Choose Us
**Optimum solution for wide range product application
For cleaning paper pulp slurry and stock preparation, we provide a range of pulp cleaners. In addition to low density pulp cleansers, we also supply high density pollutants and hydrocyclones with both light and high consistency. In addition, we offer wear spare parts including feed heads, top shells, lower cones, reject chambers, clamps, and hoses. We use premium materials in the construction of our products to guarantee their long-term performance.
**Strictly-selected raw materials
Beichen sources premium raw materials for all of its pulp cleaner and ceramic dewatering element products, as well as premium Alumina powder, SiC ceramic, and SiN ceramic spare parts, to keep a competitive advantage in the papermaking machinery market. Carton steel, stainless steel 304/316, and the high strength FRP base are all examples of excellent quality.
They are the cornerstone and foundation of Beichen Company's product.
**Know-how technology
Beichen has the technological expertise to manufacture exceptional hydrocyclone cleansers with both high and low density and light consistency. Beichen produces professional ceramic dewatering elements at a variety of prices.
We understand the consistency ranges, operating principles, and installation requirements for various pulp cleaner types. In addition, we use cutting-edge technology to produce durable ceramic cones.
We are familiar with the many types of forming boards, hydrofoil boxes, flat suction boxes, low vacuum suction boxes, high vacuum suction boxes, and felt suction boxes for ceramic dewatering components. Our understanding of the characteristics of SiC, SiN, and alumina ceramics is comprehensive. Expert specialists in mounting and grinding ensure outstanding ceramic coatings and blades.
**Skilled and focusing operation
Beichen specializes in all stages of production, including raw material selection, cone isostatic pressing, CNC and manual grinding, ceramic attachment, guide rail CNC grinding, and inspection.
This can assure the long-term functioning of all products, help clients improve their entire production capacity, and reduce overall operating expenses.
**Strict Inspection
Before shipment, each product must be thoroughly inspected.
All pulp cleaners, spare parts, and ceramic dewatering components are thoroughly reviewed to ensure that they fit the size, composition, and technical criteria outlined in the drawings.
**Comprehensive service
We provide service before and after sale, for providing better solutions to clients.
Prior to purchase
◎ Assist clients in selecting the appropriate item with expert technological and business advice.
◎ Accurate size and material application using field sketching
◎ Tailored product schedules based on customer specifications
◎ Accessible online twenty-four hours a day
Following purchase
◎ Secure and prompt delivery
◎ Helping our customers construct the apparatus
◎ Visit clients to address production issues and train first-line workers on the job
